Ultrasonic Cleaning Bath
Product Details:
- Temperature +5 C to 60 C. Celsius (oC)
- Usage New
- Click to View more
Ultrasonic Cleaning Bath Price And Quantity
- 1 Unit
- 54900 INR
Ultrasonic Cleaning Bath Product Specifications
- New
- +5 C to 60 C. Celsius (oC)
Ultrasonic Cleaning Bath Trade Information
- Udaipur
- 100 Unit Unit Per Month
- 15 Days
- Australia Western Europe Middle East Africa Central America South America Asia Eastern Europe North America
- All India
Product Description
APPLICATIONS- A compact and easy operate Ultrasonic Bath manufactured with advanced MOSFET technology.
- Designed to clean small and dismantled intricate parts at an operating frequency range of 33Khz ±3KHz.
- Fitted with Microprocessor Based Digital Temperature Indicator-Cum-Controller at any temperature from ambient +5 C to 60 C.
- Also fitted with digital timer with a settable range from 0-15 min or 0-30 min (depending upon the capacity ordered).
- Extensively protected electronic circuits mean longer and safer operations.
- High-frequency electrical energy is converted into ultrasound waves by means of ULTRASONIC TRANSDUCERS.
- Compact, rugged and highly durable system.
- The efficiency of 90% permits maximum cleaning action, low power consumption.
- Extensively protected electronic circuits mean longer and safer operations.
- Automatic frequency tuning for maximum output.
- The input range of 170VAC-270VAC, highest immunity to input supply variations.
- Pre-set Auto Degassing function.
- Pulse Sweep Power for better effective cleaning.
- To work on 220/230 V AC Supply.
TECHNICAL SPECIFICATIONS & ORDERING INFORMATIONS
| MODEL | #UCB-50 (Jointed) |
| CAPACITY | 5.0 ltrs |
| MOC (Outer) | Stainless Steel Sheet buffed to mirror polish |
| MOC (Tank) | Stainless Steel Sheet (SS-304) |
| Insulation | High-Grade Mineral Glass Wool |
| Heater | Industrial Grade Energy efficient heaters. |
| Temperature Range | Ambient +50C to 600C. |
| Temperature Controller | Microprocessor Based PID Digital Temperature Indicator-cum-Controller |
| Display | Digital LED Display with Set Value (SV) & Process Value (PV) (For Digitally Controlled Unit) |
| Temperature Accuracy | +10C |
| Operating frequency | 33 KHz +3KHz |
| Timer (Micro Controller Based) | Fitted with Digital Timer as a standard feature |
| Standard Accessory | Supplied with network basket. |
| Safety Feature | Digital tuning of a transducer with generators to avoid any frequency shift |
