Water Bath Rectangular (Double Walled)

13800 INR

Temperature 100 C +0.5 C Fahrenheit (oF)
Usage Users Self-compensation function to control difference between real temperature and indicated temperature.
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Water Bath Rectangular (Double Walled) Price And Quantity

Temperature 100 C +0.5 C Fahrenheit (oF)
Usage Users Self-compensation function to control difference between real temperature and indicated temperature.

FOB Port Udaipur
Supply Ability 100 Unit Unit Per Month
Delivery Time 15 Days
Main Export Market(s) Western Europe Australia North America Eastern Europe Africa Middle East South America Asia Central America

APPLICATIONS

User's Self-compensation function to control the difference between real temperature and indicated temperature.
Stainless steel bath for superior Durability and High Thermal efficiency.
Flat Stainless Steel Lid with Concentric rings prevents evaporation.
Industrial grade energy efficient heaters reduce power bills drastically.

CONSTRUCTIONS

Double walled construction.
Space between the walls is filled with special grade mineral wool in order to avoid thermal losses.
A drain plug is also fitted to the unit for user convenience.
The unit can be supplied with or without stirring arrangement.
The stirring arrangement consists of an FHP motor with SS stirring shaft.
MOC (Inner): Inner bath chamber and lid made of Stainless Steel (SS-304 grade).
MOC (Outer): Outer chamber is made of M.S. sheet duly powder coated.
Concentric rings can be removed to accommodate containers of various sizes.
To work on 220/230 AC supply.

TECHNICAL SPECIFICATION & ORDERING INFORMATIONS
WATER BATH RECTANGULAR (DOUBLE WALLED) THERMOSTATIC MODEL

MODEL	WBRT-6
Internal Dimensions (LXWXD)	300X250X100 mm
No. of Holes	6 Holes of 75 mm Dia
Capacity	8 ltrs
Heating Load	1.0 KW
Temperature Controller	Hydraulic Type Capillary Thermostat
Temperature Range	From ambient to 100 C (+0.5 C)
Stirring Device (OPTION)	Available with or without stirring arrangement with the help of FHP stirrer (as Ordered)
Temperature Display	Thru L-shaped prismatic thermometer (Not supplied with the unit)
Diffuser Shelf	Heater protective perforated cover made of Stainless Steel
